Grader Blade
Tough, Reliable, and Ready for Any Job
You work long days in tough conditions, so your gear needs to keep up. That’s why we build machinery that’s rugged, low-maintenance, and ready to roll when the job demands it—no matter the soil, crop, or season.
We focus on what matters to you: better soil results, faster turnaround, and fewer breakdowns. Every feature is designed to help you cover more ground with less hassle and more confidence.
And when you need backup, we’re here. Our team stands by every machine we build, with honest advice, real support, and a shared commitment to making your farm more productive.
Australian Made
Family owned and operated as well as Australian Designed and built for Aussie farmers and Aussie conditions.
Aussie Made
Overview
The Grizzly Grader Blade is absolute quality and strength.
If your looking for a 3 point linkage mounted hydraulic adjustment Grader Blade that’s seriously versatile then Grizzly has the machine for you.
The Grizzly Heavy Duty Grader Blade certainly packs a punch and is loaded with features that means it will be a reliable piece of equipment for many years to come.
Whether for renovating or making tracks, cleaning out culverts or table drains, making channels or watercourses or any other application you have for it you know you will be able to rely on the Grizzly Grader Blade.
Features
Offset Blade can be hydraulic or manually o set to 840mm (2’9″) from center, giving a total travel of 1.68m (5’6″).
Tilt Degree of blade tilt can be set +/-28° hydraulically from the comfort of the tractor.
Rear Wheel 360° rotation of the rear wheel allows effortless forward and reverse operation to fine tune finish.
Blade Angle Hydraulically adjusted blade angles enable streamline grading of roadways, also gives the ability to move more dirt in one pass.
High Clearance Heavy-duty mainframe gives strength and 700mm underframe clearance allows for greater carrying capacity without fouling.
Reinforced Turntable High-density polyethylene wear plate enables fully lubricated pivot surface between mainframe and blade making for easy service and replaceable wear point.
Designed to never seize even when left outdoors and can be adjusted over time.
Reinforced Blade 10mm thick reinforced blade with replaceable hardened 15mm thick cutting edge and a height of 500mm (18”).
Standard Rear Wheel Designed with extra length of 1.1m behind the blade gives optimum stability and smoothness while grading tracks and roadways.
Optional Electric Over Hydraulic For tractors with insufficient hydraulic remotes, the option of electric over hydraulic control allows 1 tractor remote to operate 2 hydraulic cylinders.
Easy Accessible Service Points All moving points on the machine are fully greaseable and easily accessible to minimize wear and maximize working life.
3 Point Linkage Suits CAT 2, 3, and 4 also compatible with quick hitch.
Reversible Blade Blade can be reversed easily by unpinning blade angle cylinder, turning the blade manually, and pinning in an allocated hole. Makes an ideal push blade.
Grader Blade Specifications
| Model | GB006 | GB008 | GB010 |
|---|---|---|---|
| Description | 6′ Hyrdraulic | 8′ Hyrdraulic | 10′ Hyrdraulic |
| Blade Length | 1.8m (6′) | 2.4m (8′) | 3m (10′) |
| Weight – Excludes Options | 710kg | 740kg | 770kg |
| Blade Height | 500m Reinforced | ||
| Blade Thickness | 10mm Reinforced | ||
| Cutting Edge | 155mm height x 15mm thick – replaceable | ||
| Blade Edge | Reinforced with 200mm x 75mm RHS channel across the full blade width | ||
| Blade Style | 360° full circle – push blade, hydraulic operated | ||
| Minimum Power Required | 80hp | 100hp | 120hp |
| Maximum Power | 150hp | 175hp | 200hp |
| Under Frame Clearance | 820mm – giving excellent clearance | ||
| Angle Control | Hyrdraulic | ||
| Tilt Control | Hyrdraulic | ||
| Offset Control | Hydraulic is standard, manual is optional | ||
| Hydraulics – Angle | 3 1⁄2″ x 18″ cylinder | ||
| Hydraulics – Tilt | 2 1⁄2″ x 8″ cylinder | ||
| Hydraulics – Offset | 2 1⁄2″ x 12″ cylinder | ||
| Degree of Angle | +/- 45° | ||
| Degree of Tilt | +/- 28° | ||
| Offset Distance | +/- 840mm (Total movement 1.68m) | ||
| Linkage Size | CAT 2 & 3 – CAT 3 Quick Hitch Standard | ||
| Turntable Information | 20mm on 25mm plate steel with a 440mm diameter with a 10mm HD Polyethylene ant-seize wear plate. Designed to never seize even when left outdoors and can be adjusted over time. | ||
| Main Beam Size | Reinforced 150mm x 150mm x 9mm RHS. | ||
Grader Blade Options
| Manual Depth Wheel | Manual Adjust Rear Depth Control Wheel – 185/75R 14″ | ||
| Hydraulic Depth Wheel | Hydraulic Adjust Rear Depth Control Wheel – 185/75R 14″ | ||
| Hydraulic Diverters | Cuts down hydraulic control banks needed on tractor. | ||
